Meiji are now established as one of the leading manufacturers of Japanese microscopes. The ML7500 metallurgical microscope is available as binocular or trinocular, with an infinity corrected optical system for reflected light brightfield, darkfield and polarisation techniques.

A large stable stand of excellent build quality, and a vertical illuminator with full Kohler design.

•The viewing head is inclined at 30 degrees and fully rotatable. Paired DIN standard super widefield x10 eyepieces with a field of view of 20mm. The interpupillary distance is adjustable between 52 and 72mm

•Extra large, revolving quadruple ball-bearing nosepiece with infinity corrected: S Plan brightfield/darkfield objectives. BDS Plan Met x4, BDS Plan Met x10, BDS Plan Met x20 and BDS Plan Met x40. x60 BDS and x100 brightfield objectives available as accessories.

•Rectangular mechanical stage - 172 x 130mm with 100 x 100mm travel. Equipped with precision ball bearing guides and low position drop down coaxial controls.

•Kohler vertical illuminator with 12v 50watt halogen light source. Infinity system lens, field iris, aperture iris and filter slot. Capable of brightfield, darkfield or reflected light polarisation technique. Includes blue, green, yellow and neutral density filters in mounts. The transformer and variable rheostat control are built into the microscope base.

•Coaxial low position coarse and fine focus controls, graduated in 2 micron divisions. Tension adjustment and safety auto stop. Focus range 35mm.
Dimensions 200 x 410 x 525mm. Weight 10.5Kgs

Full colour brochure on request.

Prices:
Binocular £3250
Trinocular £3450
