Brunel SP03 and SP14 Microscopes

Brunel SP03/SP14 Series

The Wedmore SP series microscopes are a range of high quality, high performance instruments available exclusively from Brunel Microscopes. The robust design of these instruments is particularly suited to the rigours of education establishments and the dedicated amateur naturalist. All Wedmore SP microscopes are equipped with RMS standard thread achromatic objectives, a full substage Abbe condenser (N.A. 1.2), with iris diaphragm, filter carrier and full rack and pinion adjustment.

Quadruple objective turret. Separate coarse and fine focus controls. Square specimen stage with slide clips, which can also accommodate a mechanical specimen driver. Illumination is by plano/concave mirror, which can be replaced by a substage 240v (110v available), 20 watt lamp unit which provides optimum illumination at all magnifications.

Dimensions 320 x 120 x 180mm. Weight 3.5 kg approx.

Wedmore SP03

Achromatic objectives x10, x40. Eyepieces x10, x15. Full substage condenser with iris diaphragm. Mechanical specimen driver. Magnification range x100 - x600.

Price £106.67 + vat

Wedmore SP14

Achromatic objectives x4 x10, x40, x100 (oil). Eyepieces x10, x15. Full mechanical stage with drop down coaxial controls, not often available with this type of instrument. LED Substage Lamp 240 volts fits in place of the mirror and wooden case. An excellent  microscope and without equal in its price range.

Magnification range x40 to x1500.

Price £175.83  + vat

Biological Microscopes

Wedmore SP03 Microscope

Wedmore SP14 Microscope

x15 widefield eyepiece                       WDMRE-01


x10 Phase contrast                           WDMRE-11


x20 widefield eyepiece                       WDMRE-02


x40 Phase contrast                           WDMRE-12


x4 objective                                      WDMRE-03


Mechanical stage                              WDMRE-13


x63 objective                                    WDMRE-04


Measuring eyepiece                          WDMRE-14


x100 objective (oil)                             WDMRE-05


Photography adapter                         WDMRE-15


Digital camera adapter                       WDMRE-06


Photoeyepiece                                  WDMRE-16


Stage micrometer                              WDMRE-07


Dark Ground Condenser                   WDMRE-17


T2 ring (state camera)                        WDMRE-08


Eyecam digital camera                     WDMRE-18


 Polariser/Analyser                            WDMRE-09


Demonstration eyepiece                    WDMRE-19


Wooden case                                   WDMRE-10


Wedmore Microscope Accessories

The Wedmore series has a range of accessories available from our online shop.
