Impressive optical performance and durable build quality

Brunel SP100 Microscope

This is an advanced specification microscope, elegantly designed and finished in ivory enamel with a blue back plate. This microscope is available exclusively from Brunel Microscopes and is recommended because of its impressive optical performance as a  laboratory specification microscope and its durable construction that makes it ideal for a microscope that will have heavy usage. It has a build quality comparable to instruments of a far greater price that are currently considered the market leaders. The SP100 is equipped with an excellent set of plan objectives. In our opinion this represents the best value microscope currently available.


Four position objective turret with a precise internal indexing mechanism. Parfocal DIN standard plan objectives x4, x10, x40, x100 (oil), matched with extremely widefield plan x10 eyepieces. x25 and x60 objectives are available as accessories.The microscope head is rotatable through 360 degrees and has full dioptric and interocular adjustment. The trinocular head has a sliding prism that diverts the light alternatively between the trinocular tube and the binocular eyetubes.


The large mechanical stage measures 135 x 125mm with a movement range of 75 x 35mm, and has drop down coaxial controls and double vernier scales. The substage condenser (N.A. 1.25) has a full rack and pinion control mechanism, centring adjusters and an iris diaphragm and filter carrier. The low position coaxial coarse and fine focus system in includes a tension adjustment and variable safety stop. The safety stop can also be used as a prefocus device as it does not effect the fine focus movement. The Kohler  Illumination is by a particularly effective LED system which provides enhanced brightness with no heat gain. The back plate has a power cord tidy feature. From a quality point of view, this is as good as it gets for this price without equal.



SP100 Trinocular with plan objectives           Price £665.00 + vat




x20 widefield eyepieces (pair)      SP100-01

£48.34

Carrying  case                            SP100-09

£41.67

x10 measuring eyepiece              SP100-02

£28.33

Polariser/Analyser  set                SP100-10

£35.00

Stage micrometer                       SP100-03

£24.17

CCTV adapter                             SP100-11

£33.33

SLR Photography attachment      SP100-04

£37.50

Dark ground condenser (dry)        SP100-12

£52.50

T2 ring (state camera)                 SP100-05

£13.33

Dark ground condenser (oil)         SP100-13

£63.33

x3.2 photoeyepiece                    SP100-06

£25.83

Zernike phase contrast system     SP100-14

£275.83

Digiadapt for SP100-04               SP100-07

£12.50

x25 Plan objective                        SP100-15

£43.33

Universal DSLR adapter              SP100-08

£145.00

x60 Plan objective                        SP100-16

£52.50

Brunel SP100 Microscope Accessories


The Brunel SP100 accessories include a full phase contrast kit and dark ground condensers which makes this a very versatile instrument. The most recent addition to the accessory range is an excellent carrying case.


Microscope dimensions 410 x 190 x 240mm.   Weight 5.5 Kg

Biological Microscopes

Monocular microscopes

Brunel SP100 Microscope

Objective

Working Distance

N.A.

x4

23.13mm

0.10

x10

4.09mm

0.25

x40

0.60mm

0.65

x100

0.38mm

1.25

Objective specification
