Brunel SP300 Biological Microscope

A biological microscope with exceptional phase contrast/brightfield imaging

The Brunel SP300 trinocular microscope complies with the test slide reading required by the Health and Safety Executive for asbestos fibre counting which makes it exceptional in the world of phase contrast. These are robust industrial microscopes finished to a very high standard and with a very modern design. The light source is a Kohler LED unit integral to the base of the microscope. This makes the microscope an ideal instrument for phase contrast applications, and the trinocular SP300 is, we believe, the lowest priced phase contrast microscope that meets the HSE specification for asbestos fibre counting that is currently available and these specifications are exacting. We are confident therefore that whatever your phase contrast requirements are - particularly for diatom identification - this is the microscope that delivers

A particular feature is the large rectangular mechanical stage with drop down co-axial controls. The SP300 is specifically configured to provide the optical specifications needed for phase contrast. This consists of infinity corrected x4 bright field and x10, x20, x40 and x100 (oil immersion) plan brightfield/phase contrast objectives together with an easy to operate Zernicke phase contrast condenser with matching phase rings. The extra wide field x10 eyepieces are excellent and have integral fitted eyecups. The SP300 can also be supplied with plan bright field objectives and a standard condenser. The phase contrast items can be added at a later date if required. The co-axial coarse and fine focus controls have a graduation reading in 2 microns for an estimate of depth measurement.  The total focus range covers 35mm and the movement runs in extra wide precision ball-bearing hardened steel tracks. Tension adjustment and safety auto focus stop units are fitted as standard.

The specific feature of the Brunel SP300 microscope is the potential flexibility, both in optical performance and image capture systems.The stand below the trinocular head has a slot for the introduction of an analyser polarisation filter and the field lens has an indent for a polarising filter allowing basic polarisation examination of specimens.

We believe that at this budget there is no other microscope that can offer this flexibility and excellent results with phase contrast microscopy. There is an custom made carrying case with suitcase style handle and wheels which makes the SP300 truly portable. There is also a wide range of accessories.

Brunel SP300 Bright field: Price £1329.17+ vat

Brunel SP300 Phase contrast/Bright field: Price £2141.67 + vat

x20 widefield eyepieces - pair   SP300-01


Measuring eyepiece                 SP300-04


Stage micrometer                    SP300-02


Aluminium carrying case          SP300-05


CCTV adapter                         SP300-03


SLR photography adapter         SP300-06


Dark Field condenser - dry        SP300-07


Dark Field condenser - oil          SP300-08


Polariser/analyser set               SP300-09


Heated Stage                           SP300-10
